Product presentation
ZHT4
LED Module 108W
Product applications
Applications
Lighting system for professional applications, sports facilities, harbours, parking areas, camping grounds. Outdoor illumination for buildings, monuments and churches. Lighting for industrial buildings, working and emergency lamps.
Product description
Description
ZHT4 is a modular lighting system, IP65 certified, that can be used for countless applications. The system combines energy saving, light
supply flexibility, orientation and beam aperture and easy installation. Thanks to its special optics, ZHT4 is able to meet the most
diverse lighting requirement. This model allows external modules to tilt independently by up to 40°, making the use of this system
even more flexible.
Product features
Features
- Painted aluminum body, polycarbonate cover
- High color rendering
- Great uniformity and light efficiency
- More than 10 different optics available
- Easy installation and economic management
- Great flexibility of use and long life (> 50.000 h)
Product specifics
Technical specifications
| Voltage/Frequency |
100~240V(AC)/50~60Hz |
| Consumption |
108W ± 5% |
| Light flow |
> 8.600 lm |
| Colour temperature |
5.000 - 6.000 ± 10% K |
| Light efficiency |
> 75 lm/W |
| Output colour index |
(CRI) > 75 |
| Use temperature |
-20°C ~ 50°C |
| Use humidity |
10% ~ 85% RH |
| Duration* |
> 50.000 hrs |
| Weight (Kg) |
5.1 |
| Protection index |
IP65 |
| RoHS - CE - UL |
Compliant |
* It maintains more than 70% of the initial light
Application sample
Product photometric data
Photometric data
Photometric curve with TIR-45 optics
Photometric curve with T3 optics
Photometric curve with T5 optics
Photometric curve with T1 optics
Product datasheet
Models
- EFF108N4AE LED FIXTURE 108W DC - CW - TYPE3
- EFF108N4AD LED FIXTURE 108W DC - CW - TIR45
- Energy saving up to 75%
- The different optics available provide great flexibility in orientation and beam design (available in different colour temperatures)
- Modular use (low, medium and high power systems may be obtained by installing multiple modules)
- Designed to be installed on any type of support
- Low voltage supply
- Wide range of power supply for electric system’s connection, available for single or multiple installation of the modules
- IP65 certified for outdoor use
- Life cycle higher than 50.000 hours
